Description
- NEW SCS 770069 Power Relay Compatibility - Controls power to workbenches, hand tools, and other electronic devices dependent on the WS Aware Monitor’s status
- Dual Workstation Continuous Monitor - Continuously monitors the path-to-ground integrity of two operators, two conductive or dissipative worksurfaces, and two metal tools; meets ANSI/ESD S20.20 in accordance with ESD TR1.0-01-01.
- Ethernet Connectivity - Provides network communication with Static Management Program (SMP). Data collected through SMP includes operator resistance, operator voltage, mat resistance, metal tool impedance and metal tool EMI voltage.
- Digital Signal Processing Technology - Applies an ultra-low test voltage to the operator (0.05V) for the handling of sensitive components.
- Operator Body Voltage Detection Alarms if the operator generates or contacts voltage that would be dangerous to an ESD susceptible item.
- EMI Monitoring on Metal Grounds - Alarms if the grounded metal tools have high-frequency noise that could cause electrical overstress (EOS) damage.
- System Includes Monitor and Two Remote Terminals - Monitor can be installed at eye level, and remote terminals can be mounted at desired locations up to 10 feet away. Each remote terminal includes a monitored jack for operators and an unmonitored jack for visitors.
- Use with Dual-Wire Wrist Straps
- Replaceable Dual-Wire Operator Jack - Use the CTA245 Replacement Jack PCB to easily replace the operator jack without the use of solder.
- Calibration Unit Available for Accurate Performance and Conformity Testing in the Field - See SCS item CTE701.
- NIST Calibrated - Calibrated with accepted procedures and standards traceable to the National Institute of Standards and Technology.
- 100-240VAC Power Adapter with Interchangeable Plugs - Works with standard electrical systems in North America, United Kingdom, Japan, Asia and Europe.
- Made in the United States of America - This item is made and stocked in Chino, CA.
